OPTEX FTN-ST Ανιχνευτής κουρτίνας εξωτερικός άνω και κάτω δέσμης με εμβέλεια 5m max
ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
| Detection method | Passive infrared | |
| PIRcoverage | 16'5"×3'3" (5x1m) | |
| Detection length limit | 6'7", 16'5" (2m, 5m) | |
| Detectable speed | 1' - 4'11"/s (0.3 - 1.5 m/s) | |
| Sensitivity | 3.6F [ at 2'/s] (2.0C [at 0.6 m/s]) | |
| Operation voltage | 9.5 - 18 V DC | |
| Current draw | 17mA(max.) (at 12 V DC) | 20mA(max.) (at 12 V DC) |
| Alarm period | 2.0 1.0sec. | |
| Warm-up Period | Approx. 60 sec. (LED blinks) | |
| Alarm output | N.C./N.O. Selectable 28 V DC 0.1 A (max.) | |
| Trouble Output | N.C. 28 V DC 0.1 A (max.), open when the cover is removed. | |
| LED Indicator | Light/Blink: Warm-up, alarm, masking detection (FTN-AM only) | |
| Operation Temperature | -4 - +140F (-20 - +60C) | |
| Environment Humidity | 95% max. | |
| IP Rating | IP55 | |
| Mounting | Wall (Outdoor, Indoor) | |
| Mounting Height | 2'7" - 3'11" (0.8 - 1.2 m) | |
|
